Item/Type

MSWP

Lift Rated Capacity

kg

240

Max. Working Height

mm

5000

Max.platform Height

mm

3000

Overall Length

mm

1180

Overall Width

mm

760

Overall Height

mm

1830

Platform Size

mm

1170*600

Ground Clearance

mm

60

Wheel Base

mm

990

Min. Turning Radius

mm

1200

Driving Motor

V/kw

2*24/0.4

Lifting Motor

V/kw

24/0.8

Running Speed（Platform Stowed）

Km/h

4

Running Speed（Platform Stowed）

Km/h

0.8

Rising / Falling Speed

sec

20/30

Battery

V/Ah

2*12/80

Charger

V/A

24/12

Max. Climbing Ability

%

10-15

Max. Working Allowable Angle

/

2°

Driving Wheel

mm

230*80

Front Wheel

in

6

Net Weight

kg

490
