Type CGP431 Features Timeless and stylish design Integrated with the latest innovative CosmoPolis system for lower energy consumption, outstanding lighting performance and bright, natural white light Well-concealed screw design on the spigot for post-top installation effortlessly synchronizes the luminaire with the pole and with its environment as well as facilitates fast installation Adjustable lamp holder position and a choice of flat glass and bowl glass deliver maximum flexibility for different road use and appearance High quality gasket and high strength construction deliver an IP66 rating for the whole luminaire Long lasting, high-pressure die cast housing Tool-less ‘click & release’ gear tray and housing contribute less maintenance time and savings in cost Re-lamping from below provides easy access to the lamp and prevent water from dropping into the luminaire during wet conditions Light source HID: 1 x MASTER CosmoPolis CPO-T White / PGZ12 / 60, 140 W 1 x SON-T/ E27 / 70 W 1 x SON-T/ E40 / 150, 250 W Lamp included No Yes (K) Gear Electromagnetic (low loss), 230 or 240 V / 50 Hz: Inductive (IN) Electronic, 220 - 240 V / 50 - 60 Hz: High Frequency (HF) Electronic (EB) Optics CosmoPolis optic (OC) Facetted open CT-POT (OR) Optical cover Flat glass (FG) Glass bowl (BG) Materials and finish Non corrosive high-pressure die-cast aluminum for the canopy and frame High purity aluminum reflector Toughened glass bowl and flat glass High quality silicon rubber gasket Standard color: RAL7043 (GR) Installation Post-top mounting: axial entry Ø 60 or 76 mm (76P) Side-entry mounting: lateral entry Ø 42 to 60 mm (60S) Classifcations IP66 IK05 Main applications Urban, residential, pedestrian and shopping areas, squares, local streets, minor collector roads, parks
