Type BPP406 1-module/2-module/3-module/4-module Features Contemporary design - Its contemporary design provides urban planners with a creative solution for street applications Energy-efficient white-light solution - Delivers a uniform and visually comfortable white light with good color rendering of around 80. - Available in two color temperatures: warm white (3000K) and neutral white (4000K). - High-power LEDs combined with smart optics offer an environmentally friendly solution— consuming up to 50% less energy than traditional street lighting Flexible range to meet application and user needs - Enables architects, urban planners and lighting designers to address multiple lighting applications in residential areas. - Comprises of four luminaire configurations and a dedicated mast, available in several heights — suitable for a wide variety of locations and environments Light source 6/12/18/24 High Power LEDs 700 mA Light color Warm White 3000 K Neutral White 4000 K Color rendering index -80 Power supply 110-240 VAC / 50-60 Hz Power consumption System ~18 W/ 35W/52 W/69W (typically) Optic Combination of collimator and reflector Driver Integrated in mast Installation Recommended mounting height: 4, 5 and 6 m Post top on dedicated mast Materials and finishing Housing and bracket: die-cast aluminum Philips silver grey paint Optic: Anodized reflector; lenses in methacrylate Cover: Tempered glass Ambient temperature -20ºC < Ta < +35ºC Lifetime 50,000 hours (70% lumen maintenance) Classifcations IP65 Class I, Class II IK07 Accessories ZPP406 Remarks No light pollution Luminaire fixed under angle of 10°C Functional earth needed for Class II Main applications Residential areas
